Gigabyte B760M DS3H WIFI6E GEN5 DDR5 LGA 1700 Micro-ATX Motherboard
SKU: 39531877
Rs 45,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Gigabyte B760M DS3H WIFI6E GEN5 DDR5 LGA 1700 Micro-ATX Motherboard
SKU: 39531877
Rs 45,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Payment Methods:
Overview
A compact yet feature-rich motherboard supporting 12th–14th Gen Intel CPUs. Equipped with four DDR5 DIMM slots (up to 256 GB), a PCIe 5.0 x16 slot, dual PCIe 4.0 M.2 and four SATA ports for versatile storage, plus next-gen connectivity including Wi‑Fi 6E (Intel AX210, BT 5.3), 2.5 GbE LAN, and USB 3.2 Gen 2 Type‑C. Ideal for high-performance, future-ready builds in a micro‑ATX form factor.
- PCIe Gen5 Performance : Perfect Sync to Win
- Supports Intel® Core™ 14th/ 13th /12th processors
- WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
- WIFI Compass : Auto detects the best antenna position for strongest Wi-Fi signal.
- EZ-Latch : PCIe 5.0×16 Slot with Quick Release Design
- PCIe UD Slot : SMD PCIe 5.0 Armor for enhanced graphics card support
- Unparalleled Performance : Hybrid 6+2+1 Phases VRM Solution
- Dual Channel DDR5 : 4*DIMMs XMP Memory Module Support
- Fast Networks : 2.5 GbE LAN & Wi-Fi 802.11ax
- Next Generation Storage : 2*PCIe 4.0 x4 M.2 Connectors
- Extended Connectivity : Rear USB-C® 10Gb/s, DP, HDMI
- Smart Fan 6 : Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus : Update BIOS Without Installing the CPU, Memory and Graphics Card
Overview
A compact yet feature-rich motherboard supporting 12th–14th Gen Intel CPUs. Equipped with four DDR5 DIMM slots (up to 256 GB), a PCIe 5.0 x16 slot, dual PCIe 4.0 M.2 and four SATA ports for versatile storage, plus next-gen connectivity including Wi‑Fi 6E (Intel AX210, BT 5.3), 2.5 GbE LAN, and USB 3.2 Gen 2 Type‑C. Ideal for high-performance, future-ready builds in a micro‑ATX form factor.
- PCIe Gen5 Performance : Perfect Sync to Win
- Supports Intel® Core™ 14th/ 13th /12th processors
- WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
- WIFI Compass : Auto detects the best antenna position for strongest Wi-Fi signal.
- EZ-Latch : PCIe 5.0×16 Slot with Quick Release Design
- PCIe UD Slot : SMD PCIe 5.0 Armor for enhanced graphics card support
- Unparalleled Performance : Hybrid 6+2+1 Phases VRM Solution
- Dual Channel DDR5 : 4*DIMMs XMP Memory Module Support
- Fast Networks : 2.5 GbE LAN & Wi-Fi 802.11ax
- Next Generation Storage : 2*PCIe 4.0 x4 M.2 Connectors
- Extended Connectivity : Rear USB-C® 10Gb/s, DP, HDMI
- Smart Fan 6 : Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus : Update BIOS Without Installing the CPU, Memory and Graphics Card
| CPU | LGA1700 socket: Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors L3 cache varies by CPU (See GIGABYTE's website for latest CPU support list) |
|---|---|
| Chipset | Intel® B760 Express Chipset |
| Memory | 14th & 13th Gen i9/i7: DDR5 5600/5200/4800/4400 MT/s 13th Gen i5/i3 & 12th Gen CPUs: DDR5 4800/4400 MT/s 4 x DDR5 DIMM sockets (up to 256 GB) Dual channel architecture ECC/Non-ECC Un-buffered DIMMs supported Supports Extreme Memory Profile (XMP) |
| Onboard Graphics | Intel® HD Graphics (depends on CPU) - 1 x HDMI (4096x2160@60 Hz, HDMI 2.1, HDCP 2.3) - 2 x DisplayPort (4096x2304@60 Hz, DP 1.2, HDCP 2.3) Supports triple display output |
| Audio | Realtek® Audio CODEC High Definition Audio, 2/4/5.1/7.1-channel Supports S/PDIF Out * Audio jack function customizable via software |
| LAN | Realtek® 2.5GbE LAN (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Intel® Wi-Fi 6E AX210 - Wi-Fi a/b/g/n/ac/ax (2.4/5/6 GHz) - Bluetooth® 5.3 - Supports 11ax 160MHz * Actual data rate depends on environment |
| Expansion Slots | CPU: - 1 x PCIe x16 (PCIe 5.0, graphics card or NVMe SSD only) Chipset: - 2 x PCIe x1 (PCIe 3.0) |
| Storage Interface | CPU: 1 x M.2 (2280, PCIe 4.0 x4/x2) — M2A_CPU Chipset: 1 x M.2 (2280, PCIe 4.0 x4/x2) — M2P_SB 4 x SATA 6Gb/s Supports RAID 0/1/5/10 (SATA only) |
| USB Ports | Back Panel: - 1 x USB Type-C® (USB 3.2 Gen 2) - 3 x USB 3.2 Gen 1 - 2 x USB 2.0/1.1 Internal: - 2 x USB 3.2 Gen 1 (via header) - 4 x USB 2.0/1.1 (via headers) |
| Internal Connectors | 1 x 24-pin ATX power 1 x 8-pin ATX 12V 1 x CPU fan header 3 x system fan headers 2 x ARGB Gen2 headers 1 x RGB LED header 2 x M.2 connectors 4 x SATA 6Gb/s 1 x Front panel header 1 x Front audio header 1 x S/PDIF Out header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x TPM header (supports GC-TPM2.0 SPI variants) 1 x Q-Flash Plus button 1 x Reset jumper 1 x Clear CMOS jumper |
| Back Panel I/O | 2 x USB 2.0/1.1 1 x PS/2 keyboard/mouse port 2 x Antenna connectors 1 x HDMI 2 x DisplayPort 3 x USB 3.2 Gen 1 1 x USB Type-C® (USB 3.2 Gen 2) 1 x RJ-45 LAN 3 x Audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| Hardware Monitoring | Voltage, temperature, fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Fan speed control support depends on installed fan |
| BIOS | 1 x 128 Mbit flash AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC) - Q-Flash, Q-Flash Plus, Smart Backup * GCC features vary by model |
| Bundled Software | Norton® Internet Security (OEM version) |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX (24.4cm x 24.4cm) |
