GIGABYTE B760M GAMING PLUS WIFI DDR4 LGA 1700 Micro-ATX Motherboard
SKU: 39179558
Rs 39,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
GIGABYTE B760M GAMING PLUS WIFI DDR4 LGA 1700 Micro-ATX Motherboard
SKU: 39179558
Rs 39,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Payment Methods:
Overview
New and seasoned builders alike can lay the foundation to their next fresh build or replace their current motherboard with the Gigabyte B760M GAMING PLUS WIFI DDR4 LGA 1700 Micro-ATX Motherboard. Sporting a B760 chipset, you get access to an Intel LGA 1700 socket which supports a wide range of 12th, 13th, and 14th Gen processors. Four dual-channel DDR4 RAM slots can support up to 128GB of memory with max overclocking speeds of 5333 MHz, allowing you to use modules you may currently own. Amass your storage solution with four SATA and two M.2 PCIe interfaces. Install graphics and utility cards with one PCIe 4.0 x16 and two PCIe 3.0 x1 expansion slots. Between the internal headers and back panel, you get access to an array of USB 2.0 and 3.2 Gen 1 ports for your peripherals. You can also use Bluetooth 5.3 technology to connect wireless devices for a true cable-free experience. With several 3.5mm combo audio jacks and Realtek Audio CODEC, you get immersive 7.1-channel audio for your media, games, and even conference calls. Connect to your network wired or wirelessly with a Gigabit Ethernet port or Wi-Fi 6 technology, respectively. The GAMING PLUS WIFI DDR4 supports Windows 10 and 11 operating systems.
- Intel LGA 1700 Socket: Supports 14th, 13th, and 12th Gen Processors
- DDR4 Compatible: Dual Channel DDR4, 4 DIMMs
- Sturdy Power Design: Hybrid 4+1+1 Phases Digital VRM Solution
- Next Gen Connectivity: 2*PCIe 4.0 x4 M.2, Front USB 3.2 Gen 1 Type-C
- Fast Networking: LAN, Wi-Fi 6
- Fine Tuning Features: Smart Fan 6, Q-Flash Plus
Overview
New and seasoned builders alike can lay the foundation to their next fresh build or replace their current motherboard with the Gigabyte B760M GAMING PLUS WIFI DDR4 LGA 1700 Micro-ATX Motherboard. Sporting a B760 chipset, you get access to an Intel LGA 1700 socket which supports a wide range of 12th, 13th, and 14th Gen processors. Four dual-channel DDR4 RAM slots can support up to 128GB of memory with max overclocking speeds of 5333 MHz, allowing you to use modules you may currently own. Amass your storage solution with four SATA and two M.2 PCIe interfaces. Install graphics and utility cards with one PCIe 4.0 x16 and two PCIe 3.0 x1 expansion slots. Between the internal headers and back panel, you get access to an array of USB 2.0 and 3.2 Gen 1 ports for your peripherals. You can also use Bluetooth 5.3 technology to connect wireless devices for a true cable-free experience. With several 3.5mm combo audio jacks and Realtek Audio CODEC, you get immersive 7.1-channel audio for your media, games, and even conference calls. Connect to your network wired or wirelessly with a Gigabit Ethernet port or Wi-Fi 6 technology, respectively. The GAMING PLUS WIFI DDR4 supports Windows 10 and 11 operating systems.
- Intel LGA 1700 Socket: Supports 14th, 13th, and 12th Gen Processors
- DDR4 Compatible: Dual Channel DDR4, 4 DIMMs
- Sturdy Power Design: Hybrid 4+1+1 Phases Digital VRM Solution
- Next Gen Connectivity: 2*PCIe 4.0 x4 M.2, Front USB 3.2 Gen 1 Type-C
- Fast Networking: LAN, Wi-Fi 6
- Fine Tuning Features: Smart Fan 6, Q-Flash Plus
CPU
- Socket: LGA1700
- Supported CPUs: 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors
- L3 Cache: Varies with CPU (Refer to "CPU Support List")
Chipset
- Chipset: Intel® B760 Express Chipset
Memory
- Supported Memory Types: DDR4 5333(O.C.) to 2133 MT/s
- DIMM Slots: 4 x DDR4 DIMM (Max 128 GB, 32 GB per DIMM)
- Dual Channel Architecture
- Memory Features: ECC Un-buffered DIMM (non-ECC mode), Non-ECC Un-buffered DIMM (1Rx8/2Rx8/1Rx16), Extreme Memory Profile (XMP)
- Note: Memory configuration may affect supported memory types, speed, and number of modules (Refer to "Memory Support List")
Onboard Graphics
- Integrated Graphics Processor: Intel® HD Graphics support
- Ports: 1 x HDMI (4096x2160@60 Hz, HDMI 2.1, HDCP 2.3), 1 x DisplayPort (4096x2304@60 Hz, DisplayPort 1.2, HDCP 2.3)
- Triple-Display Support
Audio
- Audio Codec: Realtek® Audio CODEC
- Supported Channels: 2/4/5.1/7.1-channel
- Additional Features: S/PDIF Out Support, Configurable audio software for 7.1-channel audio
LAN and Wireless
- LAN: Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
- Wireless: Realtek® Wi-Fi 6 RTL8851BE (Wi-Fi a, b, g, n, ac, ax, Bluetooth 5.3)
- Wi-Fi Features: 2.4/5 GHz bands, 160 MHz wireless standard support
Expansion Slots
- 1 x PCIe x16 Slot (PCIe 4.0)
- 2 x PCIe x1 Slots (PCIe 3.0)
Storage
- M.2 Slots: 2 x M.2 connectors (PCIe 4.0 x4/x2 SSD support)
- SATA Ports: 4 x SATA 6Gb/s connectors
- RAID Support: RAID 0, 1, 5, and 10 for SATA devices
USB Ports
- 5 x USB 3.2 Gen 1 (3 back panel, 2 internal)
- 2 x USB 2.0 (back panel)
- 4 x USB 2.0 (internal headers)
- 1 x USB Type-C® (internal, USB 3.2 Gen 1)
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x CPU fan header
- 3 x system fan headers
- 1 x addressable LED strip header
- 1 x RGB LED strip header
- 1 x USB 3.2 Gen 1 header
- 1 x USB Type-C® header
- 1 x Trusted Platform Module header
- 1 x Q-Flash Plus button
Back Panel Connectors
- 2 x USB 2.0/1.1
- 3 x USB 3.2 Gen 1
- 1 x DisplayPort
- 1 x HDMI
- 1 x RJ-45 LAN Port
- 3 x Audio Jacks
- 2 x SMA Antenna Connectors
I/O Controller
- iTE® I/O Controller Chip
BIOS
- 128 Mbit Flash, AMI UEFI BIOS
- Supports ACPI 5.0, SM BIOS 2.7
Bundled Software
- Norton® Internet Security (OEM version)
- LAN bandwidth management software
Operating System
- Windows 10 64-bit and Windows 11 64-bit
Form Factor
- Micro ATX (24.4 cm x 24.4 cm)
