MSI B450M-A Pro Max II ProSeries Motherboard

SKU: 39040688
Model: B450M-A Pro Max II

Rs 22,490

Authorised Dealer

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

  • Need help? Ask our Experts

MSI B450M-A Pro Max II ProSeries Motherboard

SKU: 39040688
Model: B450M-A Pro Max II

Rs 22,490

Authorised Dealer

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

Payment Methods:

Payment methods 1.jpg
  • Need help? Ask our Experts

Overview

DIY FRIENDLY MSI motherboards feature tons of convenient and smart design, such as convenient pin-header keep out zone, friendly SATA & USB location and so on, so DIY users can pick and choose any gaming rig they want.

  • Supports AMD Ryzen 5000, 4000, 3000, 2000, and 1000 Series desktop processors and Athlon with Radeon Vega Graphics desktop processors
  • Supports DDR4 Memory, up to 4133 (OC) MHz
  • Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
  • Audio Boost: Reward your ears with studio grade sound quality
  • 2.5G LAN: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection

Overview

DIY FRIENDLY MSI motherboards feature tons of convenient and smart design, such as convenient pin-header keep out zone, friendly SATA & USB location and so on, so DIY users can pick and choose any gaming rig they want.

  • Supports AMD Ryzen 5000, 4000, 3000, 2000, and 1000 Series desktop processors and Athlon with Radeon Vega Graphics desktop processors
  • Supports DDR4 Memory, up to 4133 (OC) MHz
  • Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
  • Audio Boost: Reward your ears with studio grade sound quality
  • 2.5G LAN: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection

Chipset:
AMD B450

CPU Support:
Supports AMD Ryzenâ„¢ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series, and 1000 Series Desktop Processors
Supports Athlonâ„¢ with Radeonâ„¢ Vega Graphics Desktop Processors
Socket: AM4

Memory Support:
2x DDR4 DIMMs
Maximum Capacity: 64GB
Memory Speeds:

  • 2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133 MHz (by A-XMP OC MODE)
    Supports Dual-Channel mode
    Supports non-ECC, UDIMM memory
    Supports ECC UDIMM memory (non-ECC mode)
    Supports un-buffered memory

Onboard Graphics:
1x HDMIâ„¢ 2.0b with HDR
Maximum Resolution: 4K 60Hz (only with CPUs featuring integrated graphics)
1x DVI-D
Maximum Resolution: 1920x1200 60Hz

Expansion Slots:
1x PCI-E x16 slot (PCI-E 3.0, up to x16, from CPU)
1x PCI-E x1 slot (PCI-E 2.0, up to x1, from Chipset)

Audio:
Realtek® ALC897 Codec
7.1-Channel High Definition Audio

Storage Support:
1x M.2 Slot

  • M.2_1 (From CPU): PCIe 3.0 x4 / SATA (supports 2280/2260/2242 devices)
    4x SATA 6Gbps
    RAID Support:
  • RAID 0, RAID 1, RAID 10 (for SATA storage devices)

USB Ports:

  • 2x USB 2.0 (Rear)
  • 4x USB 2.0 (Front)
  • 4x USB 5Gbps Type-A (Rear)
  • 2x USB 5Gbps Type-A (Front)

LAN:
Realtek® 8125 2.5Gbps LAN Controller

Internal I/O Connectors:

  • 1x ATX_PWR (Power Connector)
  • 1x CPU_PWR (Power Connector)
  • 1x CPU Fan
  • 1x System Fan
  • 2x Front Panel (JFP)
  • 1x Chassis Intrusion (JCI)
  • 1x Front Audio (JAUD)
  • 1x COM Port (JCOM)
  • 1x TPM pin header (Supports TPM 2.0)
  • 4x USB 2.0 ports
  • 2x USB 5Gbps Type-A ports

Back Panel Ports:

  • Keyboard/Mouse
  • DVI-D
  • HDMIâ„¢
  • 1x USB 3.2 Gen 1 5Gbps Type-A
  • 2.5G LAN
  • Audio Connectors
  • USB 2.0

Operating System Support:

  • Windows® 11 64-bit
  • Windows® 10 64-bit
