MSI B850 GAMING PLUS WIFI Motherboard
SKU: 39849738
Rs 68,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
MSI B850 GAMING PLUS WIFI Motherboard
SKU: 39849738
Rs 68,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Payment Methods:
Overview
- ULTRA POWER – SUPPORTS THE LATEST RYZEN 9000 PROCESSORS IN HIGH PERFORMANCE – The MSI B850 GAMING PLUS WIFI employs a 12 Duet Rail Power System (P-PAK) VRM for the AMD B850 chipset (AM5, Ryzen 9000 / 8000 / 7000) with Core Boost architecture
- FROZR GUARD – Excellent cooling features such as 7W/mK MOSFET thermal pads, extra choke thermal pads and an Extended Heatsink; Includes chipset heatsink, EZ M.2 Shield Frozr II, a Combo-fan (for pump & system) header (3A)
- DDR5 MEMORY, PCIe 5.0 x16 SLOT – 4 x DDR5 DIMM SMT slots enable excellent memory overclocking speeds (1DPC 1R, 8200+ MT/s OC); 1 x PCIe 5.0 x16 SMT slot (128GB/s) with Steel Armor supports cutting-edge graphics cards
- TRIPLE M.2 CONNECTORS – Storage options include 1 x M.2 Gen5 x4 128Gbps slot with EZ M.2 Shield Frozr II to prevent thermal throttling, 1 x M.2 Gen4 x4 64Gbps slot and 1 x M.2 Gen4 x2 32Gbps slot
- CONNECTIVITY – Network hardware includes a full-speed Wi-Fi 7 module with Bluetooth 5.4 & 5Gbps LAN; Rear ports include USB 10Gbps Type-C and 7.1 HD Audio with Audio Boost
Overview
- ULTRA POWER – SUPPORTS THE LATEST RYZEN 9000 PROCESSORS IN HIGH PERFORMANCE – The MSI B850 GAMING PLUS WIFI employs a 12 Duet Rail Power System (P-PAK) VRM for the AMD B850 chipset (AM5, Ryzen 9000 / 8000 / 7000) with Core Boost architecture
- FROZR GUARD – Excellent cooling features such as 7W/mK MOSFET thermal pads, extra choke thermal pads and an Extended Heatsink; Includes chipset heatsink, EZ M.2 Shield Frozr II, a Combo-fan (for pump & system) header (3A)
- DDR5 MEMORY, PCIe 5.0 x16 SLOT – 4 x DDR5 DIMM SMT slots enable excellent memory overclocking speeds (1DPC 1R, 8200+ MT/s OC); 1 x PCIe 5.0 x16 SMT slot (128GB/s) with Steel Armor supports cutting-edge graphics cards
- TRIPLE M.2 CONNECTORS – Storage options include 1 x M.2 Gen5 x4 128Gbps slot with EZ M.2 Shield Frozr II to prevent thermal throttling, 1 x M.2 Gen4 x4 64Gbps slot and 1 x M.2 Gen4 x2 32Gbps slot
- CONNECTIVITY – Network hardware includes a full-speed Wi-Fi 7 module with Bluetooth 5.4 & 5Gbps LAN; Rear ports include USB 10Gbps Type-C and 7.1 HD Audio with Audio Boost
Chipset & CPU Support
- Chipset: AMD B850
- CPU Support: AMD Ryzenâ„¢ 9000 / 8000 / 7000 Series Desktop Processors
- Socket: AM5
Memory
- Slots: 4x DDR5 UDIMM
- Maximum Capacity: 256GB
- Supported Speeds:
- Overclocked (OC): DDR5 8200 - 5600 MT/s
- JEDEC Standard: DDR5 5600 - 4800 MT/s
- Ryzenâ„¢ 9000 Series Maximum Overclocking:
- 1DPC 1R: Up to 8200+ MT/s
- 1DPC 2R: Up to 6400+ MT/s
- 2DPC 1R: Up to 6400+ MT/s
- 2DPC 2R: Up to 4800+ MT/s
- Features:
- Supports AMD EXPOâ„¢
- Supports Dual-Channel Mode
- Supports Non-ECC, Un-buffered Memory
- Supports CUDIMM (Clock Driver Bypass Mode Only)
Onboard Graphics
- 1x DisplayPort (DP 1.2)
- Max Resolution: 4K @ 60Hz*
Only available on processors with integrated graphics.
Expansion Slots
- Total Slots: 4x PCI-E x16
- Slot Configurations:
- PCI_E1: PCIe 5.0 x16 (from CPU)
- PCI_E2: PCIe 3.0 x1 (from Chipset)
- PCI_E3: PCIe 4.0 x4 (from Chipset)
- PCI_E4: PCIe 3.0 x1 (from Chipset)
- CPU-Based PCIe Support:
- Ryzenâ„¢ 9000 / 7000: PCIe 5.0 x16
- Ryzenâ„¢ 8700 / 8600 / 8400: PCIe 4.0 x8
- Ryzenâ„¢ 8500 / 8300: PCIe 4.0 x4
- Note: PCI_E2, PCI_E3 & PCI_E4 share bandwidth; PCI_E3 will run at x2 when devices are installed in PCI_E2 or PCI_E4.
Audio
- Codec: Realtek® ALC897
- Channels: 7.1-Channel High Definition Audio
Storage
- M.2 Slots:
- M.2_1 (CPU): PCIe 5.0 x4 (2280/2260)
- M.2_2 (CPU): PCIe 4.0 x4 (22110/2280)
- M.2_3 (Chipset): PCIe 4.0 x2 (2280/2260)
- SATA Ports: 4x SATA 6G
- RAID Support: RAID 0 & RAID 1 (M.2 NVMe)
USB Ports
- Rear I/O:
- 4x USB 2.0
- 1x USB 5Gbps Type-A
- 1x USB 10Gbps Type-A
- 2x USB 10Gbps Type-C
- Front I/O:
- 4x USB 2.0
- 4x USB 5Gbps Type-A
- 1x USB 5Gbps Type-C
Networking
- Wired LAN: Realtek® 8126VB 5G LAN
- Wireless LAN: Wi-Fi 7 (Pre-installed M.2 Key-E module)
- MU-MIMO TX/RX
- 2.4GHz / 5GHz / 6GHz (320MHz)
- Max speed up to 5.8Gbps
- Supports 802.11 a/b/g/n/ac/ax/be
- Bluetooth: Bluetooth® 5.4 (Requires Windows 11 24H2)
Internal I/O
- Power Connectors:
- 1x 24-pin ATX_PWR
- 2x 8-pin CPU_PWR
- 1x 8-pin PCIe_PWR
- Fan Headers:
- 1x CPU Fan
- 1x Combo Fan (Pump/Sys Fan)
- 4x System Fan
- Additional Headers:
- 1x EZ Conn-header (JAF_1)
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x COM Port (JCOM)
- 1x Tuning Controller (JDASH)
- 3x Addressable V2 RGB LED (JARGB_V2)
- 1x RGB LED (JRGB)
- 1x TPM 2.0 Header
LED Features
- 4x EZ Debug LED
