TP-Link XZ000-G7 1-Port Gigabit XPON Terminal Modem
SKU: 39461431
Model:
XZ000-G7
Rs 4,190
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
TP-Link XZ000-G7 1-Port Gigabit XPON Terminal Modem
SKU: 39461431
Model:
XZ000-G7
Rs 4,190
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Payment Methods:

Overview
The TP-Link XZ000-G7 is a combo terminal that supports both GPON (Gigabit Passive Optical Network) and EPON (Ethernet Passive Optical Network), making it suitable for Fiber-to-the-Home solutions. It features one PON port and one gigabit LAN port, providing fast transfer speeds and flexibility for fiber internet access.
- Gigabit Internet Access:Â One PON port and one gigabit LAN port provide fast transfer speeds
- XPON Support:Â EPON + GPON dual mode offers greater flexibility for fiber internet access.
- Ease of Use:Â Quick and hassle-free installation with intelligent power-saving.
- Remote Management:Â Supports the OMCI (ONU Management Control Interface) protocol for centralized configuration and management.
Overview
The TP-Link XZ000-G7 is a combo terminal that supports both GPON (Gigabit Passive Optical Network) and EPON (Ethernet Passive Optical Network), making it suitable for Fiber-to-the-Home solutions. It features one PON port and one gigabit LAN port, providing fast transfer speeds and flexibility for fiber internet access.
- Gigabit Internet Access:Â One PON port and one gigabit LAN port provide fast transfer speeds
- XPON Support:Â EPON + GPON dual mode offers greater flexibility for fiber internet access.
- Ease of Use:Â Quick and hassle-free installation with intelligent power-saving.
- Remote Management:Â Supports the OMCI (ONU Management Control Interface) protocol for centralized configuration and management.
Hardware Features
- Interface:
- 1 × PON Port (SC/UPC)
- 1 × 10/100/1000 Mbps RJ45 Port
- Button: 1 × RESET Button
- External Power Supply: 9VDC/0.6A
- IEEE Standards: IEEE 802.3, 802.3u, 802.1p, 802.1Q
- Data Rates:
- Downstream Speeds: 2.488 Gbps (GPON), 1.25 Gbps (EPON)*
- Upstream Speeds: 1.244 Gbps (GPON), 1.25 Gbps (EPON)*
- Wavelength:
- Upstream: 1310 nm
- Downstream: 1490 nm
- Dimensions (W x D x H): 3.7 × 3.0 × 1.2 in (95.0 × 75.0 × 29.3 mm)
- Distance: 0–20 Km Max
- GPON Standards: ITU-T G.988, G.984.1, G.984.2, G.984.3, G.984.4
- Optical Module: Class B+
- Receiver: Super-TIA
- Transmitter: DFB Laser
Software Features
- Advanced Features:
- Upstream and Downstream FEC
- Dynamic Bandwidth Allocation (DBA) support for NSR/SR
- Up to 16 T-CONTs and 256 GEM Ports
- Optical power detection
- Dying Gasp
- Terminal Silent mechanism
- VLAN:
- 802.1Q tag VLAN
- VLAN transparent mode, VLAN translation mode, VLAN trunk mode
- Authentication based on SN and Password
- VLAN Auto Detect
- Security:
- AES Encryption
- Packet Filter based on VLAN
- Management:
- Local: WebGUI, Telnet
- Remote: OMCI
- IGMP: IGMP v1/v2/v3
Others
- Package Contents:
- XPON Terminal XZ000-G7
- Power Adapter
- Quick Installation Guide
- Requirements:
- Operating Systems: Microsoft Windows 98SE/NT/2000/XP/Vistaâ„¢/7/8/8.1/10, MAC OS, NetWare, UNIX, or Linux
- Browsers: Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browsers
- Subscription with an Internet Service Provider (for Internet access)
- Certifications: CE, RoHS
- Environment:
- Operating Temperature: 0℃–40℃ (32℉–104℉)
- Storage Temperature: -40℃–60℃ (-40℉–140℉)
- Operating Humidity: 10%–90% non-condensing
- Storage Humidity: 5%–90% non-condensing
