ASUS PRIME B760M-K D4 Intel B760 LGA 1700 mATX Motherboard
SKU: 39542770
Rs 29,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
ASUS PRIME B760M-K D4 Intel B760 LGA 1700 mATX Motherboard
SKU: 39542770
Rs 29,990
Authorised Dealer
Out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Payment Methods:
Overview
ASUS Prime B760M-K D4, an Intel®B760 LGA 1700 mATX motherboard with PCIe 4.0, two PCIe 4.0 M.2 slots, DDR4, Realtek 2.5Gb Ethernet, VGA, HDMI®, SATA 6 Gbps, front USB 3.2 Gen 1, Aura Sync.
- Intel® LGA 1700 Socket
- Ultrafast Connectivity
- Comprehensive Cooling
- Aura Sync RGB Lighting
Overview
ASUS Prime B760M-K D4, an Intel®B760 LGA 1700 mATX motherboard with PCIe 4.0, two PCIe 4.0 M.2 slots, DDR4, Realtek 2.5Gb Ethernet, VGA, HDMI®, SATA 6 Gbps, front USB 3.2 Gen 1, Aura Sync.
- Intel® LGA 1700 Socket
- Ultrafast Connectivity
- Comprehensive Cooling
- Aura Sync RGB Lighting
CPU Support
- Socket Type: Intel® Socket LGA1700
- Compatible Processors:
- Intel® Core™ 14th & 13th Gen
- Intel® Core™ 12th Gen
- Intel® Pentium® Gold
- Intel® Celeron® Processors
- Intel® Turbo Boost Technology: Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 (depends on CPU).
Chipset
- Intel® B760 Chipset
Memory
- Memory Slots: 2 x DIMM
- Max Memory: 64GB, DDR4
- Memory Speeds: Supports overclocked memory speeds from 2133 MHz to 5333 MHz (OC).
- Architecture: Dual Channel Memory
- Intel® Extreme Memory Profile (XMP) Support
Graphics
- 1 x VGA port
- 1 x HDMI® port (Supports 4K@60Hz as specified in HDMI® 2.1)
- Graphics specifications may vary between CPU types.
Expansion Slots
- PCIe 4.0 x16 Slot (for Intel® Core™ Processors 14th, 13th & 12th Gen)
- 2 x PCIe 4.0 x1 Slots
Storage
- 2 x M.2 slots (Key M)
- 4 x SATA 6Gb/s ports
- Intel® Rapid Storage Technology: Supports SATA RAID 0/1/5/10
Ethernet
- 1 x Realtek 2.5Gb Ethernet port
USB Ports
- Rear USB (Total 6 ports):
- 4 x USB 3.2 Gen 1 ports (4 x Type-A)
- 2 x USB 2.0 ports (2 x Type-A)
- Front USB (Total 5 ports):
- 1 x USB 3.2 Gen 1 header (supports 2 additional USB 3.2 Gen 1 ports)
- 2 x USB 2.0 headers (supports 3 additional USB 2.0 ports)
Audio
- Realtek 7.1 Surround Sound High Definition Audio CODEC
- Supports Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
- Audio features include Audio Shielding, Premium audio capacitors, and Dedicated audio PCB layers.
- A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound.
Back Panel I/O Ports
- 4 x USB 3.2 Gen 1 ports (4 x Type-A)
- 2 x USB 2.0 ports (2 x Type-A)
- 1 x VGA port
- 1 x HDMI® port
- 1 x Realtek 2.5Gb Ethernet port
- 3 x Audio jacks
- 1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors
- Fan and Cooling:
- 1 x 4-pin CPU Fan header
- 1 x 4-pin Chassis Fan header
- Power:
- 1 x 24-pin Main Power connector
- 1 x 8-pin +12V Power connector
- Storage:
- 2 x M.2 slots (Key M)
- 4 x SATA 6Gb/s ports
- USB:
- 1 x USB 3.2 Gen 1 header (supports 2 additional USB 3.2 Gen 1 ports)
- 2 x USB 2.0 headers (supports 3 additional USB 2.0 ports)
- Miscellaneous:
- 2 x Addressable Gen 2 headers
- 1 x Aura RGB header
- 1 x Clear CMOS header
- 1 x COM Port header
- 1 x Front Panel Audio header (AAFP)
- 1 x S/PDIF Out header
- 1 x Speaker header
- 1 x SPI TPM header (14-1pin)
- 1 x 10-1 pin System Panel header
Special Features
- ASUS 5X PROTECTION III:
- DIGI+ VRM
- LANGuard
- Overvoltage Protection
- SafeSlot Core
- Stainless-Steel Back I/O
- ASUS Q-Design:
- Q-DIMM
- Q-LED Core
- Q-Slot
- ASUS EZ DIY:
- ProCool
- ASUS Thermal Solution:
- VRM heatsink design
- Aura Sync:
- Aura RGB header
- Addressable Gen 2 headers
Software Features
- ASUS Exclusive Software:
- Armoury Crate
- Fan Xpert
- Power Saving
- AI Suite 3
- ASUS CPU-Z
- Norton 360 Deluxe (60-day Free Trial)
- WinRAR
BIOS
- 128 Mb Flash ROM, UEFI AMI BIOS
- Manageability:
- WOL by PME
- PXE
- BIOS Features:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
Accessories Included
- Cables:
- 2 x SATA 6Gb/s cables
- Miscellaneous:
- 1 x I/O Shield
- 2 x M.2 anchors
- Documentation:
- 1 x User guide
Operating System Support
- Windows® 11, Windows® 10 (64-bit)
Form Factor
- mATX Form Factor
- Dimensions: 9.6 inches x 8.3 inches (24.4 cm x 21.1 cm)
